CV-W121 / P2202 Series

21.5 寸 TFT Full HD 16:9 显示模块平板电脑,搭载第 12 代 Intel® Core™ 处理器
产品特点
  • 21.5 寸 TFT Full HD 16:9 液晶屏,带有 5 线电阻触控 / 投影电容触控屏 / 仅玻璃面板
  • 内置 Intel® Alder Lake-P U 系列 Core™ 处理器
  • 2 个 DDR5 SO-DIMM 插槽,最高支持 4800MHz 64GB 内存
  • 四独立显示(CDS / HDMI / DP / VGA)
  • 1 个 M.2 Key E Type 2230 插槽,适用于 Intel CNVi / 无线模块
  • 采用铝合金压铸前面板设计
  • 前面板符合 IP65 防护等级
产品介绍
High Performance Industrial Panel PC (CV-100/P2000 Series)

CV-100/P2202 系列是一款高效能模块化工业平板电脑,搭载 Intel® Alder Lake-P U 系列 Core® 处理器,齐全完整的屏幕尺寸选择与灵活的扩展性是特色之一,除原生丰富的 I/O 接口 (1GbE LAN、USB3.2 Gen 2x1、COM 和 DIO),也具备 Mini PCIe、M.2 Key E Type 2230 扩展,还可利用德承专属的 CFM 扩展模块增添 PoE/IGN 等功能。通过德承专属 CDS 专利技术,对于未来电脑效能升级或是更换屏幕预留弹性升级空间,强固型 CV-100/P2202 系列工业平板电脑满足设备机台的 HMI 与生产流程可视化的多元应用。

Product Category >>>> Modular Panel PC & Industrial Monitor




高运算效能

——

CV-100/P2202 系列搭载 Intel® 7 制程的第 12 代 Core™ i5/i3 U 系列(Alder Lake-P)处理器,除了 15W 低功耗的优势外,还具有高达 10 核心 (2P+8E) 的出色效能。内置的 Intel Iris Xe 显示芯片,可轻松驾驭 AI 深度学习中所需的图像运算效能。

高运算效能

CDS 专利技术


CDS 专利技术

——

通过 CDS (Convertible Display System) 专利技术,不仅在现场端具有易维护的优势外,也可保留未来升级需求,无论是更换屏幕或是系统效能提升,只需更换单一组件即可达成,大幅节省未来升级成本。

Patent No. M482908

尺寸齐全完整

——

CV-100/P2202 系列拥有多样化的产品组合,从屏幕尺寸 (12 - 24 寸)、显示比例 (4:3 / 5:4 / 16:9) 到触控方式 (多点电容式及单点电阻式),可针对不同应用需求进行多样化选择。

尺寸齐全完整

强固、安全、更可靠



强固、安全、更可靠

——

面对严苛的使用环境,CV-100/P2202 系列具备一系列的工业级防护, 包括宽工作温度范围(-20°C 至 70°C)、宽范围直流电源输入(9 至 48VDC)、IP65 前面板防尘/防水等,有利于现场端 HMI 或生产流程可视化等应用。


视频
详细规格

CV-W121 Series

Model NameCV-W121RCV-W121CCV-W121G
DisplayLCD Size21.5” (16:9)
Max. Resolution1920 x 1080
Brightness (cd/m2)300
Contrast Ratio5000 : 1
LCD Color16.7M
Pixel Pitch (mm)0.24825 (H) x 0.24825 (V)
Viewing Angle (H-V)178 / 178
Backlight LED Life Time50,000 hrs (LED Backlight)
Touch ScreenTouchscreen TypeResistive 5-wireProjected CapacitiveGlass Screen
PhysicalDimension (W x D x H)550 x 330.5 x 63.2mm
Weight Information5.56 kg
Mechanical ConstructionDie-Casting Flat Surface
PowerPower Consumption24.85W (Max.)24.8W (Max.)24.35W (Max.)
EnvironmentFront Panel ProtectionIP 65 Compliant
Operating Temperature0°C to 60°C (with Industrial Grade peripherals; Ambient with air flow)
Storage Temperature-20°C to 60°C
Relative Humidity80% RH @ 50°C (non-Condensing)
EMCCE, UKCA, FCC, ICES-003 Class A
EMI• CISPR 32 Conducted & Radiated: Class A
• EN/BS EN 55032 Conducted & Radiated: Class A
• EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A
• EN/BS EN61000-3-3 Voltage fluctuations & flicker
• FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
EMS• EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
• EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m
• EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV
• EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV
• EN/IEC 61000-4-6 CS: 3V
• EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m
• EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz
SafetyUL, cUL, CB, IEC, EN 62368-1

P2202 Series

Model NameP2202P2202E
SystemProcessor• Onboard 12th Generation Intel® Alder Lake-P U-Series CPU:
  - Intel® Core™ i5-1245UE 10 Cores Up to 4.40 GHz, TDP 15W
  - Intel® Core™ i3-1215UE 6 Cores Up to 4.40 GHz, TDP 15W
Memory• 2x DDR5 4800MHz SO-DIMM Socket
Supports Un-buffered and non-ECC Type, Up to 64GB
BIOS• AMI BIOS
GraphicsGraphics Engine• Integrated Intel® Iris® Xe Graphics: Core™ i5-1245UE
• Integrated Intel® UHD Graphics: Core™ i3-1215UE
Maximum Display Output• Supports Quad Independent Display
CDS• 1x CDS Connector (1920 x 1080 @60Hz)
DP• 1x DisplayPort Connector (4096 x 2304 @60Hz)
  * Verified maximum resolution: 3840 x 2160 @ 60Hz
HDMI• 1x HDMI Connector (3840 x 2160 @30Hz)
VGA• 1x VGA Connector (1920 x 1200 @60Hz)
AudioAudio CodecRealtek® ALC888, High Definition Audio
Line-out1x Line-out, Phone Jack 3.5mm
Mic-in1x Mic-in, Phone Jack 3.5mm
I/OLAN• 2x 1GbE LAN, RJ45
  - GbE1: Intel® I219
  - GbE2: Intel® I210
COM• 4x RS-232/422/485 with Auto Flow Control (Supports 5V/12V), DB9
USB• 3 x USB 3.2 Gen2x1 (10Gbps), Type A
• 1 x USB 2.0 (480Mbps), Type A
DIO• 16x Isolated Digital I/O (8in/8out), 20-Pin Terminal Block
StorageSSD/HDD2x 2.5” SATA HDD/SSD Bay (SATA3.0)
RAIDSupport RAID 0/1
ExpansionMini PCI Express2x Full-size Mini-PCIe Socket
PCI Express--1x PCI or 1x PCIe x4 Expansion slot (with Optional Riser Card)
* Supports maximum dimensions of add-on card (H x L) : 111 x 169mm
SIM Socket• 1x SIM Socket
M.2• 1x M.2 Key E Type 2230 Socket, Support Intel CNVi/Wireless Module
CFM (Control Function Module) Interface• 1x CFM Interface for optional IGN Module Expansion
• 1x CFM Interface for optional PoE Module Expansion
CDS (Convertible Display System) Interface• 1x CDS Interface for Convertible Display Module
Other FunctionClear CMOS Switch• 1x Clear CMOS Switch
Reset Button• 1x Reset Button
Instant Reboot• Support 0.2sec Instant Reboot Technology
Watchdog Timer• Software Programmable Supports 256 Levels System Reset
OSD Button• LCD On/Off, Brightness Up, Brightness Down
Internal Speaker• AMP 2W + 2W
Status LED Indicator• Power LED, HDD LED
PowerPower Button• 1x ATX Power On/Off Button
Power Mode Switch• 1x AT/ATX Mode Switch
Power Input• 9 - 48VDC, 3-pin Terminal Block
Remote Power On/Off• 1x Remote Power On/Off, 2-pin Terminal Block
Max. Power Consumption• i5-1245UE CPU
  - OS Idle Mode: 49.66 W
  - Full Loading: 95.06 W
Inrush Current (Peak)• i5-1245UE CPU: 5.381 A @ 24V
Operating StystemWindows• Windows®11, Windows®10
Linux• Ubuntu 22.04
PhysicalDimension ( W x D x H )• 254.5 x 190 x 41.5 mm• 254.5 x 190 x 61 mm
Weight Information• 2.22 kg• 2.74 kg
Mechanical Construction• Extruded Aluminum with Heavy Duty Metal
Mounting• Wall / VESA / CDS / DIN Rail
Physical Design• Fanless Design
• Jumper-less Design
Reliability & ProtectionReverse Power Input Protection• Yes
Over Voltage Protection• Protection Range: 51~58V
• Protection Type: shut down operating voltage, re-power on at the preset level to recover
Over Current Protection• 15A
CMOS Battery Backup• SuperCap Integrated for CMOS Battery Maintenance-free Operation
MTBF• 216,747 Hours - Database: Telcordia SR-332 Issue3, Method 1, Case 3
EnvironmentOperating Temperature

• -40°C to 70°C
* With extended temperature peripherals; Ambient with air flow
* According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14

Storage Temperature• -40°C to 70°C
Relative Humidity• 95%RH @ 70°C (non-Condensing)
Shock• Operating, 50 Grms (w/ SSD, according to IEC60068-2-27)
Vibration• Operating, 1 Grms, 10-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-6)
• Operating, 5 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64)
EMC• CE, UKCA, FCC, ICES-003 Class A
• EN IEC 61000-6-4, EN IEC 61000-6-2 (24VDC Input Only)
EMI• CISPR 32 Conducted & Radiated: Class A
• EN/BS EN 55032 Conducted & Radiated: Class A
• EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A
• EN/BS EN61000-3-3 Voltage fluctuations & flicker
• FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
EMS

• EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
• EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 10 V/m
• EN/IEC 61000-4-4 EFT: AC Power: 2 kV; DC Power: 1 kV; Signal: 1 kV
• EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV
• EN/IEC 61000-4-6 CS: 10V
• EN/IEC 61000-4-8 PFMF: 50 Hz, 30A/m
• EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 1 cycles at 60 Hz

Safety

• UL, cUL, CB, IEC/EN 62368-1

订购信息
Available Models
Model No.Product Description
CV-W121R-R10/P2202-i5-R1021.5" TFT Full HD 16:9 Display Modular Panel PC with 12th Gen. Intel® Core™ i5-1245UE Processor and Resistive 5-wire Touch
CV-W121R-R10/P2202E-i5-R1021.5" TFT Full HD 16:9 Display Modular and Expandable Panel PC with 12th Gen. Intel® Core™ i5-1245UE Processor and Resistive 5-wire Touch
CV-W121C-R11/P2202-i5-R1021.5" TFT Full HD 16:9 Display Modular Panel PC with 12th Gen. Intel® Core™ i5-1245UE Processor and Projected Capacitive Touch
CV-W121C-R11/P2202E-i5-R1021.5" TFT Full HD 16:9 Display Modular and Expandable Panel PC with 12th Gen. Intel® Core™ i5-1245UE Processor and Projected Capacitive Touch
CV-W121G-R10/P2202-i5-R1021.5" TFT Full HD 16:9 Display Modular Panel PC with 12th Gen. Intel® Core™ i5-1245UE Processor and without Touch
CV-W121G-R10/P2202E-i5-R1021.5" TFT Full HD 16:9 Display Modular and Expandable Panel PC with 12th Gen. Intel® Core™ i5-1245UE Processor and without Touch
CV-W121R-R10/P2202-i3-R1021.5" TFT Full HD 16:9 Display Modular Panel PC with 12th Gen. Intel® Core™ i3-1215UE Processor and Resistive 5-wire Touch
CV-W121R-R10/P2202E-i3-R1021.5" TFT Full HD 16:9 Display Modular and Expandable Panel PC with 12th Gen. Intel® Core™ i3-1215UE Processor and Resistive 5-wire Touch
CV-W121C-R11/P2202-i3-R1021.5" TFT Full HD 16:9 Display Modular Panel PC with 12th Gen. Intel® Core™ i3-1215UE Processor and Projected Capacitive Touch
CV-W121C-R11/P2202E-i3-R1021.5" TFT Full HD 16:9 Display Modular and Expandable Panel PC with 12th Gen. Intel® Core™ i3-1215UE Processor and Projected Capacitive Touch
CV-W121G-R10/P2202-i3-R1021.5" TFT Full HD 16:9 Display Modular Panel PC with 12th Gen. Intel® Core™ i3-1215UE Processor and without Touch
CV-W121G-R10/P2202E-i3-R1021.5" TFT Full HD 16:9 Display Modular and Expandable Panel PC with 12th Gen. Intel® Core™ i3-1215UE Processor and without Touch

Model Configuration
 CV-W121RCV-W121CCV-W121GP2202 (i3/i5)P2202E (i3/i5)
CV-W121R/P2202V----V--
CV-W121C/P2202--V--V--
CV-W121G/P2202----VV--
CV-W121R/P2202EV------V
CV-W121C/P2202E--V----V
CV-W121G/P2202E----V--V

Package Checklist
• CV-W121/P2202 Series Panel PC x1• Thermal Pad x1
• Power Terminal Block x1• Screws Pack x5
• Remote Power On/Off Terminal Block Connector x1• Panel Mounting Kit x1
• DIO Terminal Block Connector x2• DIN Rail Mounting Kit x1
• PCI / PCIe Card Installation Kit x 1 (For P2202E Only)

Optional Modules and Accessories
Model No.Description
CFM-IGN101CFM Module with Power Ignition Sensing Control Function, 12V/24V Voltage Detection Selectable
CFM-PoE04CFM Module with PoE Control Function, Individual Port 25.5W (For P2202 Only)
CFM-PoE05CFM Module with PoE Control Function, Individual Port 25.5W (For P2202E Only)
RC-E4-02Riser Card with 1x PCIe x4 Slot (For P2202E Only)
RC-PI-02Riser Card with 1x PCI Slot (For P2202E Only)
MEC-COM-M212-TDB9Mini-PCIe Module with 2x RS-232 Ports, 1x Thin DB9 Cable (For P2202E Only)
MEC-COM-M334-TDB9Mini-PCIe Module with 4x RS-232/422/485 Ports, 2x Thin DB9 Cable (For P2202E Only)
MEC-USB-M102-30Mini-PCIe Module with 2x USB 3.0 Ports, 1x 30cm cable (For P2202E Only)
MEC-LAN-M102-30Mini-PCIe Module with 2x LAN Ports, 2x 30cm cable (For P2202E Only)
UB12031x Universal Bracket with 2x DB9 Cutout (For P2202E Only)
UB12111x Universal Bracket with 2x RJ45 Cutout (For P2202E Only)
UB12141x Universal Bracket with 2x USB Cutout (For P2202E Only)
URM01Universal 19" Rack Mount Kit for Industrial Panel PC & Industrial Monitor
GST60A12-CIN1Adapter AC/DC 12V 5A 60W, GST60A12-CIN, wide temp (-30°C ~ +70°C), level VI
GST120A24-CINAdapter AC/DC 24V 5A 120W with 3pin Terminal Block Plug and Tubes, Level VI
GST220A24-CINAdapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 5.0mm Pitch, with TUBES, level VI (For P2202E Only)
相关下载
Datasheet
文件名发行日期下载
CV-W121 / P2202 Series Datasheet2023/11/30下载
Manual
文件名发行日期下载
CV-100 / P2202 Series User Manual2024/05/07下载
Driver
文件名发行日期下载
P2200 Series Driver - Audio2023/11/30下载
P2200 Series Driver - Chipset2023/11/30下载
P2200 Series Driver - COM Port2023/11/30下载
P2200 Series Driver - GNA2023/11/30下载
P2200 Series Driver - Graphic2023/11/30下载
P2200 Series Driver - LAN2023/11/30下载
P2200 Series Driver - Intel ME2023/11/30下载
P2200 Series Driver - RAID2023/11/30下载
